Annke 8ch 8mp Nvr 5mp Poe Security Ip Camera System

ebay2023 ANNKE H500X 3K PoE IP Security Camera System with 2-Way Audio

Crystal-clear Vision, Guard Your Security

  Best 3K Def. in 16:9 Image Scale

The 1/3" progressive scan BSI CMOS image sensor delivers 3K resolution, not only bringing clearer image quality with finer details but a 16:9 image scale that is perfectly matched with the screen without distortion.

Accurate Human & Vehicle Detection

Motion Detection 2.0 recognizes and extracts key objects quickly like human beings and vehicles, reducing up to 99% false alarm.

From Black & White to Colored Night

With the default IR night vision, human/vehicle will trigger the Warm light and turn the vision into color. Customizing the B&W vision into color night vision is also supported. (100ft IR night vision and 66ft color night vision)

Real-time Two-Way Talk

You can communicate with your friends or family members anytime & anywhere, and never miss any crucial moments. Besides, you can scare the suspicious away from your premises, thieves are stopped by ANNKE’s two-way talk feature.

Flashing Alarm Light & Audible Alarm

Audible and light alarms can be linked to event triggers and real-time alerts to prevent in advance, reduce losses; there are 3 kinds of alarm sounds by default: siren, audio warning and prompt; As for flashing light alarms, 4 modes can be selected and you can adjust the time duration according to your needs.

Unlimited Smart Search & Playback

Locate Vital Videos in Countable Seconds. Never spend extra time finding what you need in loads of videos. Searching playback is much easier with updated Smart Playback tech.

Excellent WDR & 2.8MM Lens

Most security cameras fail to handle intense light affecting the image quality, but ANNKE's is tailored with smart 120db WDR/BLC/3D DNR/HLC adjustment. Even the sensors are pointed to the sun; there are no worries about unclear faces or ambiguous images. Meanwhile, 2.8mm brings you a broader vision for all-around monitoring, farewell to the blind spots.

Optional Recording and Playback

24/7 non-stop recording and auto-overwritten recording are default, or motion detection recording and schedule recording are up to you to choose. For the playback, instant playback, ordinary playback or event smart playback are supported. And extra user-friendly functions like private recording setting, lost video finding and 4 CH line crossing detection are all ready for you.

• Preset Siren Areas & Private Zones

  Freely customize some exact areas of your premise to get a more accurate alert siren or mask your private space with a digital veil. It's all up to you!

• IP67 Weatherproof

  Be it torrential downpours, freezing, or broiling temperatures (-22 °F-140 °F, 90% humidity), this IP67 weatherproof security camera braves them all.

• Remote Access with All Devices

  With free ANNKE vision App & client, you are able to access & control the camera remotely via 3G/4G/5G or WiFi from your smartphones, tablets or computers, browsers (Google Chrome, Safari, etc.).When the network camera detects any difference, it will push instant app notifications and email alerts to you to prevent possible intrusion.

• Up to 6TB HDD Supported

  This network video recorder can be inserted with a hard drive that has 6TB max storage. (HDD NOT INCLUDED). Or to save the data via a 512G max microSD card.

• Super H.265+ Compression

  Cutting-edge H.265+ codec consumers 50% less bandwidth and recording space than H.264 codec. You can record longer and smoother videos at the same video quality.

• Uncompromised Privacy

  ProtectionWith HTTPS tech, you can save the recording streams & still them in cloud storage, or local storage supported up to 128G. Both are without the risk of being hacked or shared. (Note: Micro SD Card not included.)

NVR Video & Audio Video Compression H.265+/H.265/ H.264+/H.264
IP Video Input
8CH PoE Video Output HDMI & VGA Up to 1080P Incoming Bandwidth 60M ON-VIF Protocols Support Max Recording Resolution Up to 8MP Max Playback Resolution Up to 8MP Max Playback Channel 8CH Max Playback Capacity 4-ch@1080P, 1-ch@8MP@25fps Hard Drive HDD 1 SATA Interface HDD Capacity Up to 6TB capacity
External Interface Network Interface RJ45x1(10/100M) PoE 8 Ports(IEEE802.3af/at) USB 2X USB 2.0 General Operating Power DC 48 V Power Consumption ≤10 W (Without HDD and PoE) Working Temperature '14 °F ~ 131 °F /-10 °C ~+55 °C POE: Max 25.5W for single port Dimensions (W X H X D) 10.4" × 8.9" × 1.9" / 265 × 225 × 48mm Weight (Without Hard Disk)  2.2lb / 1KG Camera Camera Image Sensor 1/2.8" Progressive Scan CMOS Video Compression Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264 Audio Compression G.711ulaw/AAC Main Stream 50 Hz: 20 fps (3072*1728, 2560 X 1440), 25 fps(1920 X 1080)
60 Hz: 20 fps (3072*1728, 2560 X 1440), 24 fps(1920 X 1080) Audio Output Built-in Speaker, max. sound pressure level: 10 cm: 95 dB Substream 50 Hz: 20 fps (1280 X 720,640 X 480, 640 X 360)
60 Hz: 20 fps (1280 X 720,640 X 480, 640 X 360) Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, DDNS, SNMP Video Bitrate 256 Kbps - 8 Mbps Lens 2.8 mm Audio Input Built-in microphone, record with audio Motion detection 2.0 Supoort, include Human & Vehicle detection Min. Illumination Color: 0.01 Lux, B/W: 0 Lux with IR Max resolution 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display Supplement Light Type Smart Dual-Light, IR Light, White Light Angle of View Horizontal FOV 104°, vertical FOV 57°, diagonal FOV 123° Image Enhancement BLC, HLC, 3D DNR Flashing Light White Light API Open Network Video Interface Version 19.12 Region of Interest (ROI) 1 fixed region for main stream Supplement Light Range IR: up to 30 m, wite Light: up to 30 m Privacy Mask 1 programmable polygon privacy mask Flashing Light Alarm High/Medium/Low Frequency/Normally On Audio Alarm Warning Sound/Prompt/Custom Audio General Function Mirror, password protection, remote access Ethernet 1 RJ45 10 M/100 M self-adaptive Ethernet port General Housing Metal & Plastic Color White Operating Power DC 12 V± 25%, max. 7.5 W; PoE (802.3af), max. 9 W Storage Built-in microSD/SDHC/SDXC Slot, up to 512 GB Hardware Reset Yes Indoor/Outdoor Use Indoor/Outdoor Dimension (L X W X H) Ø110 mm × 89.2 mm (Ø4.3" × 3.5") Operating Temperature -22 °F – 140 °F/-30 °C – 60 °C Interface Protection IP67 Weight Approx. 350 g (0.7 lb.)
